Hammond Manufacturing 166L24 Power Transformers

Hammond Manufacturing Rohs logo
166L24 Power Transformers

View larger image

  • Low Voltage/Filament Power Transformer 115V Economical Single Primary 24V CT Secondary 48VA Wires Open Style Chassis Mount
  • Jameco Part no.: 2293255
  • Manufacturer: Hammond Manufacturing
  • Manufacturer p/n: 166L24
  • NCNR (Non-Cancelable, Non-Returnable)
  • HTS code: 8504.31.4065
You May Also Like
29225-R 29225-R
Jameco ReliaPro
$14.95
102111-R 102111-R
Jameco ReliaPro
$15.95
PT-50466-R PT-50466-R
Jameco ReliaPro
$14.95
AC463-1.2-R AC463-1.2-R
Jameco ReliaPro
$11.95
SPW2304 SPW2304
Jameco ReliaPro
$6.00
TR4820-91-R TR4820-91-R
Jameco ReliaPro
$12.95

$22.15 ea

8 ship on Sep. 22

+ Add to my favorites
# of units Price
1+ $22.15
5+ $20.95
25+ $19.95
100+ $18.95

Request Larger Quantity Quote

Low Voltage/Filament Power Transformer 115V Economical Single Primary 24V CT Secondary 48VA Wires Open Style Chassis Mount

Features

  • Economical single primary 115 VAC, 60 Hz.
  • Most secondaries are center tapped (C.T.), VAC (RMS)
  • Open style, channel bracket, two hole chassis mount
  • Minimum 6" long leads
  • Dual bobbin design - no electrostatic shield required
  • We use Class B insulation (130°C) for extra protection - UL listed as a Class A (105°C) design
  • Hi-Pot test of 2,000V RMS
  • UL listed & CSA certified

Specifications

  • Primary: Single 115 VAC
  • Secondary: 24 VAC CT
  • Current: 2 A
  • Power rating: 48 VA
  • Length: 3.69"
  • Width: 2.13"
  • Height: 2.31"


Report a problem
Suggest a product
Specification Value
Product TypePower Transformer
Manufacturer Series166
Power Rating48 VA
Primary Side Voltage115 VAC
Primary Frequency60 Hz
Secondary Side Voltage24 V CT
Secondary Side Current2 A
Termination StyleWires
Length93.73 mm
Width54.10 mm
Height58.67 mm
Mounting StyleChassis
Center TapYes
Core TypeDual Bobbin
Primary Side ConnectionWires
Secondary Side ConnectionWires
Number of Outputs1
Agency ApprovalsUL, CSA
ComplianceCompliance Docs
