HellermannTyton 184-11006 Wiring Duct

High Density Slotted Wall Wiring Duct 1" x 1" Non-Adhesive PVC White 120ft per Carton

Features

• Narrow fingers reduce fanning of the wires to the terminal blocks, presenting a neater appearance.
• Each finger is provided with a double restriction to hold wires in the bottom portion of the duct, allowing for easier installation.
• Mounting holes are uniform in size and are offered every 2 inches to accommodate compact designs and ease installation.
• Optional covers snap on and off easily, and are provided with a non-slip lining that insures the covers remain in place during vibration.
• Product Type: High Density Slotted Duct and Covers

Technical Specifications

• Material: Polyvinylchloride (PVC)
• Operating Temperature: +122°F (+50°C)
• Color: White (WH)
• Storage Conditions: Store in a sealed package. Avoid direct heat sources and sunlight. Ideal storage conditions: 73°F (22.8°C), 50% RH
• Use Conditions: For Indoor Use Only
• Fixation Method: Non-Adhesive
• Height H (Imperial): 1.06"
• Height H (Metric): 26.9 mm
• Length L (Imperial): 6.0 ft
• Length L (Metric): 1.83 m
• Mounting Hole Centers (Imperial): 2.0"
• Mounting Hole Centers (Metric): 50.8 mm
• Self extinguishing (Yes/No): Yes
• Width W (Imperial): 1.0"
• Width W (Metric): 25.4 mm
• Width W2 (Imperial): 1.0"
• Width W2 (Metric): 25.4 mm
• Width W3 (Imperial): 0.16"
• Width W3 (Metric): 4.1 mm
• Width W4 (imperial): 0.4"
• Width W4 (metric): 10.2 mm
• Width W5 (imperial): 0.75"
• Width W5 (metric): 19.05 mm
• CE Certified: Yes
• CSA Certified: Yes
• Halogen Free: No
• Prop65 Warning: No
• REACH Conformity: No
• ROHS Compliant: Yes
• UL-File Number + Logo: E64139 [RU]
• UL Listed (US): No
• UL Listed (US and Canada): No
• UL Recognized (US): Yes
• UL Recognized (US and Canada): No
• UV Resistant (Yes/No): No
• UPC: 089306292760

Overview

HellermannTyton Pro-Duct High-Density, Slotted-Wall Wiring Duct features narrow fingers equaling a 2 to 1 finger ratio compared to standard slotted wiring duct. With the narrow fingers, compact designs and components are more easily accommodated.
