Name: Circuit Breaker 1C4DL 4A C CHAR 1 Pole 125VDC UL489
Brand: Altech
SKU: 2476255
Price: 30.3500 USD
Availability: OutOfStock

$30.35 ea

Series: DLS9 Series C-Trip (DC)
Rated Voltage: 125V DC
Poles: One Pole
Rated Current: 4.0A
Agency Approvals: c UL us, IEC
Current/Voltage Rating - UL Series: 0.3 - 63A/240V AC, 0.3-32A/480/277V AC
Current/Voltage Rating - DL Series: 0.3 - 63A/125/250V DC
Calibration Temperature: 40°C (104°F)
Ambient Temperature: -25°C to + 70°C (-13°F to 158°F)
Storage Temperature: -40°C to + 70°C (-40°F to 158°F)
Terminal Size Acceptability: Top:18-3 AWG; Bottom: 18-2 AWG
Terminal Torque min/max: 2 Nm (17.7 lb.in.) / 2.5Nm (22.2 lb.in)
Electrical Life: 6,000 switching cycles ON/OFF
Mechanical Life: 10,000 switching cycles ON/OFF
Vibration Resistance: >15G according to DIN EIN 60069-2-59 during a load with 1 = 1.05 x
Resistance to Mechanical Shocks: 25g @ 11ms
Ingress Protection acc. IEC/EN 60529: IP20
Mounting Orientation: In any plane

Circuit Breaker 1C4DL 4A C CHAR 1 Pole 125VDC UL489

Specification	Value
Product Type	UL489 Thermal Magnetic Breaker
Manufacturer Series	DLS9 Series C-Trip (DC)
Voltage Rating	125V DC
Current Rating	4 A
Number of Poles	1
Agency Approvals	UL, CUL, IEC
Mounting	DIN Rail
IP Rating	IP20
Minimum Operating Temperature	-25°C
Maximum Operating Temperature	70°C
Additional Feature	2 Nm (17.7 lb.in.) / 2.5Nm (22.2 lb.in)
Terminal Type	Top:18-3 AWG; Bottomz: 18-2 AWG
