BI Technologies 66WR200 Potentiometers Trimmers

BI Technologies
66WR200 Trimmers

View larger image

  • 1/2 Watt Square Cermet Potentiometer 3/8 Inch 200 Ohm 10% 20 Turn 3292-Series Equivalent
  • Jameco Part no.: 2195041
  • Manufacturer: BI Technologies
  • Manufacturer p/n: 66WR200
  • HTS code: 8533.40.8050

PRICED TO MOVE

CLOSEOUT

You May Also Like
66XR1K 66XR1K
BI Technologies
$0.79
66XR25K 66XR25K
BI Technologies
$0.49
Closeout

$0.89 ea

437 In Stock

+ Add to my favorites
# of units Price
1+ $0.89
10+ $0.79
50+ $0.69
100+ $0.59

Request Larger Quantity Quote

200 Ohms 500mW 3/8" Rectangular Cermet Trimmer Potentiometer 25-Turn Top Adjust PC Pin THM

Specifications

  • Resistance: 200 Ohms
  • Power (Watts): 0.5W, 1/2W
  • Tolerance: ±10%
  • Temperature Coefficient: ±100ppm/°C
  • Number of Turns: 25
  • Adjustment Type: Top Adjustment
  • Resistive Material: Cermet
  • Mounting Type: Through Hole
  • Termination Style: PC Pins
  • Sealed
  • Size / Dimension: Rectangular - 0.375" x 0.15 Face x 0.375"L (9.53mm x 3.81mm x 9.53mm)


Report a problem
Suggest a product
Specification Value
Manufacturer Series3292
FamilyW
Resistance (Ohm)200
Power Rating0.50 W
Tolerance10%
Product TypeTrimmer
Number of Turns20
Actuator TypeTop Slot
Termination StylePins
Shaft Diameter2.29 mm
Resistive Element MaterialCermet
TechnologySealed
Minimum Operating Temperature-65°C
Maximum Operating Temperature150°C
MountingThrough Hole
TaperLinear
Width5.08 mm
Height10.41 mm
Length9.53 mm
Temperature Coefficient100 ppm/°C
Actuator OrientationTop
Resistance200 Ohm
