Orion Fans OD6020-24HB02A DC Brushless Fans

60 mm x 60 mm x 20 mm Tube Axial Fan 24 VDC Ball Bearing 22.8CFM 33.4dBA 12" Wires (3)

Features

• Voltage Rating: 24 VDC
• Height: 60 mm
• Width: 60 mm
• Depth: 20 mm
• Air Flow (CFM): 22.8
• Bearing: Ball
• Current Rating: 150 mA
• Power Rating: 3.6 W
• Agency Approvals: UL, CUL, TUV, CE, UKCA
• Noise (dBA): 33.4
• Termination: 12" Wires (3)
• Product Type: 60mm x 60mm DC Fan
• Speed: 5550 rpm
• Maximum Pressure: 0.2 in.
• Additional Features: Open Collector Alarm Output
• Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 5550 rpm.
