MEAN WELL SKE10C-24 Encapsulated DC to DC Isolated Converters

MEAN WELL Rohs logo
SKE10C-24 Encapsulated

View larger image

  • DC-DC Regulated Single Output Converter 10W 24V 42-420mA Output 36-72Vin PC Pins
  • Jameco Part no.: 2688359
  • Manufacturer: MEAN WELL
  • Manufacturer p/n: SKE10C-24
  • NCNR (Non-Cancelable, Non-Returnable)

$$ Lowest Prices on MEAN WELL

You May Also Like
DETN01L-05 DETN01L-05
MEAN WELL
$5.45
DETN01L-12 DETN01L-12
MEAN WELL
$5.45
DETN01L-15 DETN01L-15
MEAN WELL
$5.45
DETN01M-05 DETN01M-05
MEAN WELL
$5.45
DETN01M-12 DETN01M-12
MEAN WELL
$5.45
DETN01M-15 DETN01M-15
MEAN WELL
$5.45

$19.55 ea

3 Weeks Lead Time

*This product is subject to a tariff. See detail in the cart.

+ Add to my favorites
# of units Price
10+ $19.55
50+ $18.35
200+ $17.15

Request Larger Quantity Quote

NOTE:
  • Order in multiples of 10

DC-DC Regulated Single Output Converter 10W 24V 42-420mA Output 36-72Vin PC Pins

Features

  • 2:1 wide input range
  • 1500V DC I/O isolation
  • Built-in EMI filter
  • Protections: short circuit, overload
  • Cooling by free air convection
  • Six-sided shield metal case
  • 100% full load burn-in test
  • Low cost, high reliability
  • Approvals: FCC, EAC, CE, UKCA
  • 2-year warranty


Report a problem
Suggest a product
Specification Value
Output Voltage24 VDC
Output Current0.42 A
Power Rating10 W
AC Power CordN/A
Additional Output Voltages (VDC)N/A
Input Voltage Range36 VDC to 72 VDC
Input Voltage48 VDC
Input FrequencyN/A
Maximum Input Current0.27 A
Output Connector TypePC Pins
Output Connector DiametersN/A
Pins5
Number of Outputs1
Manufacturer SeriesSKE10
Product TypeDC to DC Converter and Switching Regulator Module SMPS
Efficiency83%
Minimum Operating Temperature-25°C
Maximum Operating Temperature71°C
Length2 in.
Width1 in.
Height0.44 in.
Agency ApprovalsCE, FCC, EN, EAC, UKCA
ColorBlack
TypeRegulated
ComplianceCompliance Docs
Isolation Voltage1500V
Additional FeatureSix-sided shield metal case
