MEAN WELL DRC-40B AC to DC DIN Rail Power Supply

MEAN WELL Rohs logo
DRC-40B DIN Rail

View larger image

  • DIN Rail Switching Power Supply 27.6 Volts 0.95/0.5 Amps 40 Watts
  • Jameco Part no.: 2216753
  • Manufacturer: MEAN WELL
  • Manufacturer p/n: DRC-40B
  • NCNR (Non-Cancelable, Non-Returnable)
  • HTS code: 8504.40.9510

$$ Lowest Prices on MEAN WELL

You May Also Like
DRC-60B DRC-60B
MEAN WELL
$37.80
DRC-100B DRC-100B
MEAN WELL
$53.00
MDR-40-48 MDR-40-48
MEAN WELL
$19.20
MDR-60-48 MDR-60-48
MEAN WELL
$20.90
MDR-100-48 MDR-100-48
MEAN WELL
$36.10
SDR-240-48 SDR-240-48
MEAN WELL
$97.10
SDR-120-48 SDR-120-48
MEAN WELL
$57.80
SDR-480-48 SDR-480-48
MEAN WELL
$155.80

$31.90 ea

3 Weeks Lead Time

*This product is subject to a tariff. See detail in the cart.

+ Add to my favorites
# of units Price
1+ $31.90
5+ $30.40
10+ $29.10
20+ $28.20

Request Larger Quantity Quote

DIN Rail Switching Power Supply 27.6 Volts 0.95/0.5 Amps 40 Watts

27.6 Volts @ 0.95/0.5 Amps

Find out more about MEAN WELL Security Power Solutions.

Specifications

  • Output Power (W): 40.2
  • Ripple & Noise (mV p-p): 200
  • Load Regulation (±): 0.5%
  • Line Regulation (±): 0.5%
  • Efficiency: 87%
  • Agency Approvals: UL, CUL, TUV
  • Size (L x W x H) inches: 3.93 X 1.57 X 3.54
  • Universal AC input / Full range
  • Protections: short circuit, over voltage, overload
  • Battery low protection/Battery polarity protection by fuse
  • Can be installed on DIN rail TS-35/7.5 or 15
  • Alarm signal for AC OK and Battery low
  • Cooling by free air convection
  • LED indicates power on
  • 100% full load burn in tested
  • 3 year warranty


Report a problem
Suggest a product
Specification Value
Output Voltage27.6 VDC
Output Current0.95 A
Power Rating40 W
Input Voltage90 VAC to 264 VAC
Input Frequency47 Hz to 63 Hz
Output Connector TypeScrew Terminal Block
Agency ApprovalsUL, CUL, TUV, CB, CE, EN
Low Power Source (LPS)No
PFC FunctionNo
Additional Output Voltages (VDC)N/A
Maximum Input Current0.8 A
Manufacturer SeriesDRC-40
Efficiency87%
Minimum Operating Temperature-30°C
Maximum Operating Temperature70°C
ColorWhite
Width3.54 in.
Height3.94 in.
Depth1.57 in.
Number of Outputs1
Product TypeDIN Rail Power Supply SMPS
ComplianceCompliance Docs
