Orion Fans OD1238-48H3BVXE DC Brushless Fans

126 mm x 120 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 285.2CFM 64.6dBA 12" Wires

Features

• Voltage Rating: 48 VDC
• Height: 120 mm
• Width: 126 mm
• Depth: 38 mm
• Air Flow (CFM): 285.2
• Bearing: Ball
• Current Rating: 1600 mA
• Power Rating: 76.8 W
• Agency Approvals: UL, CUL, TUV, CE, UKCA
• Noise (dBA): 64.6
• Termination: 12" Wires
• Product Type: 120mm x 120mm DC Fan
• Speed: 5980 rpm
• Maximum Pressure: 2.3 in.
• Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 5980 rpm.
