Orion Fans OD1238-48HBXE DC Brushless Fans

120 mm x 120 mm x 38 mm Tube Axial Fan 48 VDC Ball Bearing 238.8CFM 62.1dBA 12" Wires

Features

• Voltage Rating: 48 VDC
• Height: 120 mm
• Width: 120 mm
• Depth: 38 mm
• Air Flow (CFM): 238.8
• Bearing: Ball
• Current Rating: 900 mA
• Power Rating: 43.2 W
• Agency Approvals: UL, CUL, TUV, CE, UKCA
• Noise (dBA): 62.1
• Termination: 12" Wires
• Product Type: 120mm x 120mm DC Fan
• Speed: 5175 rpm
• Maximum Pressure: 1.1 in.
• Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Electronically Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 5175 rpm.
