Orion Fans OD4010-12HSS DC Brushless Fans

40 mm x 40 mm x 10.5 mm Tube Axial Fan 12 VDC Sealed Sleeve Bearing 9.2CFM 33.2dBA 12" Wires

Features

• Voltage Rating: 12 VDC
• Height: 40 mm
• Width: 40 mm
• Depth: 10.5 mm
• Air Flow (CFM): 9.2
• Bearing: Sealed Sleeve
• Current Rating: 120 mA
• Power Rating: 1.44 W
• Agency Approvals: UL, CUL, TUV, CE, UKCA
• Noise (dBA): 33.2
• Termination: 12" Wires
• Product Type: 40mm x 40mm DC Fan
• Speed: 8000 rpm
• Maximum Pressure: 0.2 in.
• Motor Drive Type: Brushless DC, Auto Restart, Impedance Protected, Polarity Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Sealed Sleeve bearing system of the tube axial fan is designed to operate up to 8000 rpm.
