Orion Fans OD6025-12HB01A DC Brushless Fans

60 mm x 60 mm x 25 mm Tube Axial Fan 12 VDC Ball Bearing 25CFM 30dBA 12" Wires (3)

Features

• Voltage Rating: 12 VDC
• Height: 60 mm
• Width: 60 mm
• Depth: 25 mm
• Air Flow (CFM): 25
• Bearing: Ball
• Current Rating: 150 mA
• Power Rating: 1.8 W
• Agency Approvals: UL, CUL, TUV, CE, UKCA
• Noise (dBA): 30
• Termination: 12" Wires (3)
• Product Type: 60mm x 60mm DC Fan
• Speed: 3975 rpm
• Maximum Pressure: 0.22 in.
• Additional Features: Open Collector Tach Output
• Motor Drive Type: Brushless DC, Auto Cutoff, Auto Restart, Polarity Protected, Electronically Protected

Overview

Fans are a necessary component when you need to keep electronics cool or to keep the air flow moving. The Ball bearing system of the tube axial fan is designed to operate up to 3975 rpm.
