Yingjiao YSDH480-48 AC to DC DIN Rail Power Supply

Yingjiao Rohs logo
YSDH480-48 DIN Rail

View larger image

  • DIN Rail Power Supply 48 VDC 10A 480W 90VAC to 264VAC Input Higher Peak Power
  • Jameco Part no.: 2643015
  • Manufacturer: Yingjiao
  • Manufacturer p/n: YSDH480-48
  • NCNR (Non-Cancelable, Non-Returnable)
You May Also Like
SDR-480-48 SDR-480-48
MEAN WELL
$155.80
MDR-40-48 MDR-40-48
MEAN WELL
$19.20
MDR-60-48 MDR-60-48
MEAN WELL
$20.90
MDR-100-48 MDR-100-48
MEAN WELL
$36.10
SDR-240-48 SDR-240-48
MEAN WELL
$97.10
SDR-120-48 SDR-120-48
MEAN WELL
$57.80

$109.75 ea

18 Weeks Lead Time

*This product is subject to a tariff. See detail in the cart.

+ Add to my favorites
# of units Price
200+ $109.75

Request Larger Quantity Quote

NOTE:
  • Order in multiples of 200

DIN Rail Power Supply 48 VDC 10A 480W 90VAC to 264VAC Input Higher Peak Power

Features

  • Higher peak power
  • Built-in DC OK relay contact
  • Current sharing up to 3840W (7+1)
  • Built-in active PFC function
  • DC output voltage adjustable
  • 3 year warranty

Overview

Yingjiao's higher performance family of single phase DIN rail power supplies are designed with metal housing and support the full range AC input from 90 VAC to 264 VAC. With higher efficiency and current sharing up to 3840W (7+1), the entire series has built-in DC ok relay contact and allows for higher peak power while operating over a wide temperature range. This series offers diverse solutions for demanding automation around the world.



Report a problem
Suggest a product
Specification Value
Output Voltage48 VDC
Output Current10 A
Power Rating480 W
Input Voltage90 VAC to 264 VAC
Input Frequency47 Hz to 63 Hz
Output Connector TypeScrew Terminal Block
Agency ApprovalsCE, UKCA, UL
Low Power Source (LPS)No
PFC FunctionYes
Additional Output Voltages (VDC)N/A
Maximum Input Current5 A
Manufacturer SeriesYSDH480
Efficiency94%
Minimum Operating Temperature-25°C
Maximum Operating Temperature70°C
ColorGray
Minimum Isolation Voltage3000V
Width5.08 in.
Height4.92 in.
Depth3.37 in.
Number of Outputs1
Product TypeDIN Rail Power Supply SMPS
ComplianceCompliance Docs
