Yingjiao YSDN75-48 AC to DC DIN Rail Power Supply

Yingjiao Rohs logo
YSDN75-48 DIN Rail

View larger image

  • DIN Rail Power Supply 48 VDC 1.6A 76.8W 90VAC to 264VAC Input
  • Jameco Part no.: 2643079
  • Manufacturer: Yingjiao
  • Manufacturer p/n: YSDN75-48
  • NCNR (Non-Cancelable, Non-Returnable)
You May Also Like
NDR-75-48 NDR-75-48
MEAN WELL
$25.70
MDR-40-48 MDR-40-48
MEAN WELL
$19.20
MDR-60-48 MDR-60-48
MEAN WELL
$20.90
MDR-100-48 MDR-100-48
MEAN WELL
$36.10
SDR-240-48 SDR-240-48
MEAN WELL
$97.10
SDR-120-48 SDR-120-48
MEAN WELL
$57.80
SDR-480-48 SDR-480-48
MEAN WELL
$155.80

$18.95 ea

18 Weeks Lead Time

*This product is subject to a tariff. See detail in the cart.

+ Add to my favorites
# of units Price
200+ $18.95

Request Larger Quantity Quote

NOTE:
  • Order in multiples of 200

DIN Rail Power Supply 48 VDC 1.6A 76.8W 90VAC to 264VAC Input

Features

  • Universal AC input - full range
  • Free air convection design
  • Protections: Short circuit, overload, over voltage, over temperature
  • Installs on DIN Rail TS-35/7.5 & 15
  • DC output voltage adjustable
  • 3 year warranty

Overview

Yingjiao's metal case power family are designed with slim housing and with full range AC input from 90VAC to 264VAC. The series is single phase PSU providing DC OK relay contact and adjustable DC output voltage. They have high efficiency and operate in a wide temperature range. The series can be widely used for industrial automation and control systems and other equipment.



Report a problem
Suggest a product
Specification Value
Output Voltage48 VDC
Output Current1.60 A
Power Rating76.8 W
Input Voltage90 VAC to 264 VAC
Input Frequency47 Hz to 63 Hz
Output Connector TypeScrew Terminal Block
Agency ApprovalsUL, CE, UKCA
Low Power Source (LPS)No
PFC FunctionNo
Additional Output Voltages (VDC)N/A
Maximum Input Current1.45 A
Manufacturer SeriesYSDN75
Efficiency88%
Minimum Operating Temperature-20°C
Maximum Operating Temperature70°C
ColorGray
Minimum Isolation Voltage3000V
Width1.26 in.
Height4.92 in.
Depth3.96 in.
Number of Outputs1
Product TypeDIN Rail Power Supply SMPS
ComplianceCompliance Docs
