AC/DC Power Supply Single-Output 12 Volt 53A 636W

You may also like:
MHS012 MHS012
MEAN WELL
HRPG-600-12 HRPG-600-12
MEAN WELL
MSP-600-12 MSP-600-12
MEAN WELL
RS-25-12 RS-25-12
MEAN WELL
RS-15-12 RS-15-12
MEAN WELL
RS-75-12 RS-75-12
MEAN WELL
RS-150-12 RS-150-12
MEAN WELL
LRS-150-12 LRS-150-12
MEAN WELL

$141.00 ea

10 In Stock
990 ship on Dec. 27

TARIFF FREE PRODUCT


  • Jameco Part no.: 2096755
  • Manufacturer: MEAN WELL
  • Manufacturer no.: HRP-600-12
  • HTS code: 8504406012
  • Electronics Parts Locator
# of units Price
1+ $141.00
5+ $128.00
25+ $99.75

Request a Large Quantity Quote

636 W Single Output with PFC Function


12 Volts @ 53 Amps

Features:
  • Universal AC input / Full range
  • Built-in active PFC function, PF>0.95
  • Protections: Short circuit / Overload / Over voltage / Over temperature
  • With DC OK signal output
  • 5 years warranty
  • High efficiency up to 88%
  • Withstand 300VAC surge input for 5 seconds
  • Built-in constant current limiting circuit
  • Built-in cooling fan ON-OFF control (by load)
  • Built-in remote sense function
  • All using 105°C long life electrolytic capacitors



Report a problem
Suggest a product
Specification Value
Output Voltage12 VDC
Output Current53 A
Input Voltage85 VAC to 264 VAC
Input Frequency47 Hz to 63 Hz
Output Connector TypeScrew Terminal Block
Length8.6 in.
Width4.1 in.
Height2.5 in.
PFC FunctionYes
Agency ApprovalsUL, CUL, TUV, CB, CE, EN, EAC
Maximum Input Current8.5 A
Number of Outputs1
Power Rating636 W
Efficiency88%
FamilyHRP-600
Minimum Operating Temperature-30°C
Maximum Operating Temperature70°C
Minimum Isolation Voltage3000V
ColorSilver
TypeAuto Switching
StyleEnclosed
Output Voltage (Channel 1)12 VDC
Output Current (Channel 1)53 A
